RomWebClient™
IoT Device Connectivity to the Cloud
RomWebClient™ toolkit enables your embedded device to fully support HTTP 1.1 for sending and receiving HTTP objects in any format with any Web server.
RomWebClient™ Overview
Allegro’s RomWebClient™ toolkit allows your engineering team to leverage proven Web technology when creating custom IoT devices.
- The RomWebClient™ toolkit enables embedded engineering teams to build products that send and receive objects to and from any Web server using HTTP with full support for IPv4 and IPv6 operation.
- For secure communications, RomWebClient™ is tightly integrated with Allegro’s RomSTL™ TLS toolkit to make full use of TLS v1.3 with FIPS and Suite B cryptography.
- By utilizing RomWebClient™ technology your IoT devices can communicate with Cloud-based resources, download configuration files, retrieve software updates, and much more.
Contact Us
RomWebClient™
The RomWebClient™ toolkit enables your embedded device to fully support HTTP 1.1 for sending and receiving HTTP objects in any format with any local or cloud based Web server. MIME definitions for all standard MIME object types are provided in addition to allowing support for non-standard MIME types. HTTP objects can be sent or received from memory or an optional file system. Both HTTP direct requests and proxy server requests are supported. For authentication, HTTP Basic and Digest methods are provided and are compliant with RFC 2617. The RomWebClient™ toolkit also has built-in support for advanced caching, pipelined requests, proxy authentication, large object data streaming, and HTTP cookies. Delivered as ANSI-C source code the toolkit is built upon a highly portable and field-proven abstraction layer enabling it to work with any OS or TCP/IP stack.
RomXML™ and RomXML Plus™
The RomWebClient™ toolkit is pre-integrated with Allegro’s RomXML® and RomXML Plus™ toolkits allowing manufacturers to easily build advanced device management architectures that require XML, REST, JSON or SOAP-based communications with Cloud-based resources. The RomWebClient™ toolkit includes support for integrated retrieval and transmission of XML objects when used in conjunction with the RomXML® and RomXML Plus™ toolkits. This allows your design team to create devices that initiate XML-based request/response protocols such as JSON, REST and SOAP making them easier to integrate with enterprise information systems.
RomSTL™ – Embedded TLS
Security is always a concern when dealing with devices connected to the internet. RomSTL™ addresses the need for advanced security with integrated TLS 1.3 support. With support for a variety of cipher suites (RSA, DHE, RC4, DES, 3DES, AES, SHA, CBC, and MD5) and full integration with Allegro’s FIPS validated cryptography and Suite B, your development team can provide compatibility with all standard secure browsers. RomSTL™ also offers a built-in certificate authority, certificate import support and Basic and Digest Authentication under TLS. Compliant with IETF standards (RFC 8446 and RFC 5246), RomSTL™ provides RomWebClient™ with the advanced security functionality to meet your development team needs.
Highly Portable
The Allegro EdgeAgent Suite is highly portable across RTOS and processor families. Delivered in ANSI-C source code all products utilize a field-proven abstraction layer to enable portability with any RTOS, TCP/IP stack, and file system environment. Interface files for leading RTOS environments are provided.
Features |
Benefits |
| Small code footprint | More resource available for application features |
| ANSI C Source Code Distribution | Broad processor architecture support eases porting and support |
| Processor, RTOS, and TCP/IP stack agnostic | Allegro’s products will work with new or existing hardware and software designs |
| Interface files for leading RTOS vendors provided | Minimizes porting effort, decreasing time to market |
| Shipping in millions or products worldwide | Field-proven reliability |
| Supports IPv4 and IPv6 operation | Integrates with local and wide area networks |
| GPL Free | No licensing or development issues related to GPL |
| Direct and Proxy server request support along with proxy authentication | Ability to create embedded designs that directly access the Internet or interface through a proxy |
| RFC 1945 and 2616 compliant | Ability to interoperate with HTTP 1.o and HTTP 1.1 compliant servers on the Internet |
| Support for Basic and Digest authentication (RFC 2617) | Your embedded designs can support established protocols for the exchange of username and passwords for authentication |
| Support for object caching, large object streaming and pipelined request | Efficient transfer of payload data from a Web server |
| Support for HTTP cookies | Ability to support stateful communications |
| Optional TLS security | Create embedded devices with a secured communications path |
| Optional OCSP and SCEP certificate update capability | Remotely manage certificates on your embedded device |
Supported RFCs – RomWebClient™
- RFC 1945 – Hypertext Transfer Protocol — HTTP/1.0
- RFC 2616 – Hypertext Transfer Protocol — HTTP/1.1
- RFC 2617 – HTTP Authentication: Basic and Digest Access Authentication
Supported RFCs – RomSTL™ TLS
- RFC 2246 – The TLS Protocol Version 1.0
- RFC 4346 – The Transport Layer Security (TLS) Protocol Version 1.1
- RFC 8446 – THe TLS Protocol Version 1.3
- RFC 3268 – Advanced Encryption Standard (AES) Ciphersuites for Transport Layer Security (TLS)
System Requirements
- Processor Architecture – Works with any 16-bit, 32-bit or 64-bit processor
- Operating System (OS) – Works with any OS vendor and will function without an OS if needed
- TCP/IP Stack – Works with any vendor implementation
- Filesystem – Works with any vendor implementation and will function without a filesystem if needed
- Compiler – ANSI C
